Cap Remover Machine | Automatic Bottle Cap Removal System
€30.000,00
📞 Request a Quotation & Discount
Details

The Cap Removing Machine automatically removes old or used caps from polycarbonate gallon bottles (19L / 23L) before the washing and filling process begins.
This system increases production speed, reduces labor costs, and ensures hygienic pre-processing of returned bottles.

Manufactured entirely from AISI 316 stainless steel, the machine guarantees long life and resistance to chemical detergents and continuous water contact.
It can be used as a standalone unit or integrated directly into the main PC filling lines.


⚙️ Technical Specifications

Specification Detail
Model Code CR-30000
Material (Main Body & Frame) AISI 316 Stainless Steel (inner & outer)
Bottle Type 19L / 23L Polycarbonate
Working Principle Pneumatic cap removal with mechanical centering system
Capacity Up to 3,000 bottles/hour
Air Pressure 6–8 bar
Power Requirement 220V / 50Hz
Operation Mode Automatic
Dimensions (LxWxH) 1200 x 800 x 1500 mm
Certifications CE, ISO 9001, IP65 Electrical Safety

🧩 Key Features & Benefits

  • Automatically removes used gallon caps safely and efficiently

  • Fully constructed from AISI 316 stainless steel

  • Adjustable for 19L and 23L bottles

  • Pneumatic system ensures consistent performance

  • Reduces operator workload and contamination risk

  • CE-certified and food-contact safe

  • Easy to clean and maintain


🧱 Material & Build Quality

Every surface and contact component — including pneumatic holders, support frames, and cap guides — are produced using AISI 316 stainless steel.

  • Designed for long-term chemical and water exposure

  • Hygienic, corrosion-resistant, and CE compliant

  • Smooth surface finish for sanitation

  • TIG welded, IP65 electrical protection


🔧 Compatibility

Line Type Compatible Models
Polycarbonate Lines PC-1500 / PC-2400
Hybrid Lines HY-1200 (optional configuration)

💰 Pricing

€30,000
(Ex-Works Istanbul — installation and shipping not included.)


📦 Shipping & Installation

  • Lead Time: 4–6 weeks

  • Packaging: Foam padding + wooden crate

  • Delivery: Ex-Works Istanbul

  • Installation: On-site setup by AquaLine Units engineers


🛠️ Warranty & Support

  • Warranty: 1 Year (manufacturing defects)

  • Support: Remote & on-site support

  • Spare Parts: Always available

  • WhatsApp Support: +90 532 224 91 98

🔹 Shipping & Delivery

All AquaLine Units systems are shipped under EXW Istanbul (Ex-Works) terms.

Packaging includes foam padding, wooden crate, and stretch wrap for maximum protection during transport.

We assist clients with international logistics, customs documentation, and optional insurance via DHL, FedEx, or sea freight.

Delivery time: 10–12 weeks after confirmed down payment.

🏭 Local pickup and global delivery options available.

.🔹 Returns & Refund Policy

Each system is custom-built and project-specific.

Therefore, returns, refunds, and cancellations are not accepted after production has started.

🔹 Materials & Construction

All parts in contact with water are made of AISI 304 or 316 stainless steel.

Non-contact frames and covers are aluminum or galvanized steel with anti-corrosion coating.

Hoses and fittings are food-grade and BPA-free.

Electrical systems use PLC + HMI automation with CE safety standards.

🔧 Designed for long-term industrial operation and hygienic production.

🔹 Care & Maintenance

Routine maintenance is required to ensure continuous operation:


CIP (Cleaning-in-Place) recommended weekly

Lubricate mechanical moving parts monthly

Inspect filters and water lines every 3 months

Replace seals & gaskets annually

Service and spare parts support are available worldwide.

🧰 Preventive maintenance contracts available upon request.

🔹 Warranty & Support

Each line is covered by a 1-year manufacturer’s warranty against production defects.

On-site installation, commissioning, and operator training are provided by Güçlü Makine technicians.

Remote technical assistance via WhatsApp or video call is available.

Optional long-term maintenance contracts can be arranged.

📞 For service inquiries: +90 532 224 91 98 | aqualineunits@gmail.com

🔹 Safety & Compliance

CE certified manufacturing

Emergency stop buttons on all main units

Transparent protection covers on high-speed areas

Electrical compliance: EN 60204-1

Food contact materials meet EU and FDA standards

⚠️ Operator training is mandatory before running the system.

.🔹 Installation & Commissioning

Our technical team provides full setup and operator training on-site.

Installation time depends on line capacity and factory layout (average 3–5 days).

A complete FAT (Factory Acceptance Test) is done before shipment,

and a SAT (Site Acceptance Test) after installation.

🚀 Turnkey commissioning service available worldwide.
