€314.500,00
Details
Dual-mode 1200 bph hybrid filling line that supports both 19L polycarbonate and 15L glass bottles on a single integrated system.
Includes high-speed combined washing, filling, and capping modules with automatic format switching.
Developed by Güçlü Makine Ltd. and branded by AquaLine Units — engineered for maximum flexibility and efficiency.
⚙️ Detailed Description
🔹 Technical Overview
| Specification | Details |
|---|---|
| Capacity | 1200 bottles/hour (PC & Glass modes) |
| Bottle Types | 19L Polycarbonate / 15L Glass |
| Automation | PLC + HMI Touchscreen Control |
| Material | AISI 304 / 316 Stainless Steel |
| Power Supply | 380V / 50Hz |
| Air Pressure | 6–8 bar (dry, oil-free) |
| Certifications | CE Compliant |
| Warranty | 1 Year (manufacturing defects) |
| Origin | Made in Türkiye |
🔹 Main Components & Prices
| Component | Description | Price (€) |
|---|---|---|
| External Washing Machine (Dual-Mode) | Designed for both PC and glass bottles | 33,000 |
| Internal Wash + Filling + Capping Combined Unit | Adjustable nozzles for both bottle types | 220,000 |
| Safety Band Applicator | Shrink band application | 17,500 |
| Heat Tunnel | Shrink sealing | 2,500 |
| Conveyor System (30m) | Stainless steel, PC & Glass compatible | 30,000 |
| Visual Inspection Station | Manual product inspection area | 1,500 |
| Installation & Commissioning | On-site setup & operator training | 10,000 |
💶 Total Line Price:
€314,500 (EXW Istanbul)
(Optional accessories not included)
🔹 Optional Equipment
| Option | Description | Price (€) |
|---|---|---|
| Date Printer | Inkjet date/batch marking | 7,500 |
| Crate Unloading Unit | For glass bottle handling | 45,000 |
| Crate Loading Unit | For glass bottle handling | 45,000 |
| Crate Washing Machine | High-speed glass crate cleaning | 25,000 |
🔹 Advantages of Hybrid System
-
Operates with both 19L PC and 15L Glass bottles on the same line
-
Fast format changeover with minimal adjustment
-
Lower investment cost than building two separate lines
-
Ideal for bottlers offering both premium glass and standard polycarbonate products
-
Fully compatible with automated crate systems
🔹 Delivery & Service
-
Delivery Term: EXW Istanbul
-
Packaging: Foam padding + wooden crate + stretch wrap
-
Installation: Worldwide on-site setup & training
-
Lead Time: 10–12 weeks after payment confirmation
-
After-Sales Support: Remote & on-site service
-
Warranty: 1 Year (optional maintenance plan available)
🔹 Contact for Quotation
📞 Request a Quotation: Contact Form
💬 WhatsApp Direct: https://wa.me/905322249198
📧 Email: aqualineunits@gmail.com
The AquaLine HY-1200 is the ideal choice for companies seeking flexible bottling operations across two premium packaging types.
🔹 Shipping & Delivery
All AquaLine Units systems are shipped under EXW Istanbul (Ex-Works) terms.
Packaging includes foam padding, wooden crate, and stretch wrap for maximum protection during transport.
We assist clients with international logistics, customs documentation, and optional insurance via DHL, FedEx, or sea freight.
Delivery time: 10–12 weeks after confirmed down payment.
🏭 Local pickup and global delivery options available.
.🔹 Returns & Refund Policy
Each system is custom-built and project-specific.
Therefore, returns, refunds, and cancellations are not accepted after production has started.
🔹 Materials & Construction
All parts in contact with water are made of AISI 304 or 316 stainless steel.
Non-contact frames and covers are aluminum or galvanized steel with anti-corrosion coating.
Hoses and fittings are food-grade and BPA-free.
Electrical systems use PLC + HMI automation with CE safety standards.
🔧 Designed for long-term industrial operation and hygienic production.
🔹 Care & Maintenance
Routine maintenance is required to ensure continuous operation:
CIP (Cleaning-in-Place) recommended weekly
Lubricate mechanical moving parts monthly
Inspect filters and water lines every 3 months
Replace seals & gaskets annually
Service and spare parts support are available worldwide.
🧰 Preventive maintenance contracts available upon request.
🔹 Warranty & Support
Each line is covered by a 1-year manufacturer’s warranty against production defects.
On-site installation, commissioning, and operator training are provided by Güçlü Makine technicians.
Remote technical assistance via WhatsApp or video call is available.
Optional long-term maintenance contracts can be arranged.
📞 For service inquiries: +90 532 224 91 98 | aqualineunits@gmail.com
🔹 Safety & Compliance
CE certified manufacturing
Emergency stop buttons on all main units
Transparent protection covers on high-speed areas
Electrical compliance: EN 60204-1
Food contact materials meet EU and FDA standards
⚠️ Operator training is mandatory before running the system.
.🔹 Installation & Commissioning
Our technical team provides full setup and operator training on-site.
Installation time depends on line capacity and factory layout (average 3–5 days).
A complete FAT (Factory Acceptance Test) is done before shipment,
and a SAT (Site Acceptance Test) after installation.
🚀 Turnkey commissioning service available worldwide.
