Leak Tester Machine | Bottle Leakage Control System
€38.500,00
📞 Request a Quotation & Discount
Details

The Leak & Hole Test Unit is a precision-engineered control station designed to ensure airtight integrity of 15L–23L gallon bottles before filling.
By using pressurized air and vacuum sensors, the unit detects micro cracks, holes, or sealing defects that are invisible to the naked eye.
This system eliminates faulty containers, guaranteeing consistent product quality and minimizing water waste.

It is compatible with all Polycarbonate (PC), Glass, PET, and Hybrid Lines, and constructed entirely from AISI 316 stainless steel, providing unmatched corrosion resistance and hygiene standards.


⚙️ Technical Specifications

Specification Detail
Model Code LHT-2000
Material (Main Body & Surfaces) AISI 316 Stainless Steel (inner & outer)
Testing Method Air pressure & vacuum-based integrity check
Detection Range Holes ≥ 0.2 mm diameter
Cycle Time 4–6 seconds per gallon
Pressure Range 2–6 bar adjustable
Control System PLC + digital display
Operation Automatic / Semi-automatic
Power Supply 220V / 50Hz
Dimensions (mm) 1200 × 800 × 1600
Certifications CE, ISO 9001, IP65

🧩 Key Features & Benefits

  • Detects leaks, cracks, and holes before filling

  • Prevents water loss and product recall risks

  • 100% AISI 316 stainless steel body, suitable for wet environments

  • Fully automatic cycle with digital pressure readout

  • Works with PC, PET, and Glass gallon formats

  • Compact design fits between washing and filling sections

  • Long lifespan and minimal maintenance requirement


🧱 Material & Build Quality

All critical components are produced from AISI 316 stainless steel, ensuring durability in constant humidity and cleaning conditions.

  • Internal air ducts made of 316L-grade steel

  • All joints TIG-welded, polished to Ra < 0.8 µm

  • CE-certified pneumatic and electrical components

  • IP65-rated control panel for factory use


🔧 Compatibility

Line Type Compatible Models
Polycarbonate Lines PC-1500 / PC-2400
Hybrid Lines HY-1200
Glass Lines GL-1200
PET Lines PET-1200

💰 Pricing

€38,500
(Ex-Works Istanbul — installation and shipping not included.)


📦 Shipping & Installation

  • Lead Time: 4–6 weeks (manufacturing)

  • Packaging: Foam padding + wooden crate

  • Delivery: Ex-Works Istanbul

  • Installation: On-site service available by AquaLine Units engineers


🛠️ Warranty & Support

  • Warranty: 1 Year (manufacturing defects)

  • Support: Remote + on-site technical service

  • Spare Parts: In stock for immediate dispatch

  • WhatsApp Support: +90 532 224 91 98

🔹 Shipping & Delivery

All AquaLine Units systems are shipped under EXW Istanbul (Ex-Works) terms.

Packaging includes foam padding, wooden crate, and stretch wrap for maximum protection during transport.

We assist clients with international logistics, customs documentation, and optional insurance via DHL, FedEx, or sea freight.

Delivery time: 10–12 weeks after confirmed down payment.

🏭 Local pickup and global delivery options available.

.🔹 Returns & Refund Policy

Each system is custom-built and project-specific.

Therefore, returns, refunds, and cancellations are not accepted after production has started.

🔹 Materials & Construction

All parts in contact with water are made of AISI 304 or 316 stainless steel.

Non-contact frames and covers are aluminum or galvanized steel with anti-corrosion coating.

Hoses and fittings are food-grade and BPA-free.

Electrical systems use PLC + HMI automation with CE safety standards.

🔧 Designed for long-term industrial operation and hygienic production.

🔹 Care & Maintenance

Routine maintenance is required to ensure continuous operation:


CIP (Cleaning-in-Place) recommended weekly

Lubricate mechanical moving parts monthly

Inspect filters and water lines every 3 months

Replace seals & gaskets annually

Service and spare parts support are available worldwide.

🧰 Preventive maintenance contracts available upon request.

🔹 Warranty & Support

Each line is covered by a 1-year manufacturer’s warranty against production defects.

On-site installation, commissioning, and operator training are provided by Güçlü Makine technicians.

Remote technical assistance via WhatsApp or video call is available.

Optional long-term maintenance contracts can be arranged.

📞 For service inquiries: +90 532 224 91 98 | aqualineunits@gmail.com

🔹 Safety & Compliance

CE certified manufacturing

Emergency stop buttons on all main units

Transparent protection covers on high-speed areas

Electrical compliance: EN 60204-1

Food contact materials meet EU and FDA standards

⚠️ Operator training is mandatory before running the system.

.🔹 Installation & Commissioning

Our technical team provides full setup and operator training on-site.

Installation time depends on line capacity and factory layout (average 3–5 days).

A complete FAT (Factory Acceptance Test) is done before shipment,

and a SAT (Site Acceptance Test) after installation.

🚀 Turnkey commissioning service available worldwide.
